Viva Connections Adaptive Card Extensions (ACE) Guide

What Are Adaptive Card Extensions?

Adaptive Card Extensions (ACEs) are the building blocks of the Microsoft Viva Connections dashboard — the employee experience hub in Microsoft 365. Every card on the Viva Connections dashboard is an ACE.

As an SPFx developer, ACEs let you build compact, interactive dashboard widgets that surface real-time business data directly on the Viva Connections home screen. Think of them as SPFx web parts, but purpose-built for mobile-first, glanceable dashboards.

An ACE has two visual states:

• Card View — The compact card shown on the dashboard (like a widget on your phone home screen)

• Quick View — A richer, larger panel that opens when the user clicks the card (like tapping a widget to expand it)

Both are rendered using Adaptive Card JSON — the same cross-platform card format used in Teams, Outlook, and Bot Framework.

Why Build ACEs in 2026?

With Viva Connections rolling out as the default Teams home experience for many enterprise organizations, the Viva dashboard is now the first screen employees see every day. This makes ACEs one of the highest-visibility touchpoints in the entire Microsoft 365 ecosystem.

Real-world ACE use cases that are trending right now:

• IT Service Desk — Show open ticket count, let users submit new tickets

• Leave Balance Tracker — Display remaining leave days, link to the request form

• Company News Feed — Surface the latest announcements from SharePoint News

• Attendance Summary — Show today's in-office vs. remote headcount

• Project Status Tracker — At-a-glance KPIs for active projects from Planner or Dataverse

• Birthday & Anniversary Cards — Celebrate team milestones pulled from HR data

Prerequisites

Set up your environment before starting:

• SPFx 1.22+ (the modern SPFx CLI + Heft toolchain; older 1.18–1.21 still works for ACEs but is on the legacy Yeoman + Gulp path)

• Node.js 20.x LTS — use nvm to manage versions

• SPFx CLI (@microsoft/spfx-cli) for SPFx 1.22+ (or Yeoman for legacy projects)

• Microsoft 365 developer tenant with Viva Connections enabled

• Viva Connections license — included in Microsoft 365 E3/E5, or available as standalone

Verify your environment:

node --version   # Should be 20.x
npm --version    # Should be 10.x or higher
yo --version     # Should be installed globally

Step 1: Scaffold Your First ACE

Create a new project using the SPFx CLI (recommended for SPFx 1.22+):

spfx new

Alternatively, for legacy projects, you can use Yeoman:

yo @microsoft/sharepoint

When prompted:

• Solution name: leave-balance-ace

• Target: SharePoint Online only (latest)

• Place files: Current folder

• Type of client-side component: Adaptive Card Extension

• Template: Generic Card Template

• ACE name: LeaveBalanceACE

Step 2: Understand the ACE Architecture

The main ACE class extends BaseAdaptiveCardExtension and has two key methods:

• onInit() — Called when the ACE loads. Fetch your data here and set initial state

• setState() — Updates state and triggers re-render of both card and quick views

• renderCard() — Returns the ID of the card view to display

• cardNavigator / quickViewNavigator — Navigation stacks for view routing

Step 3: Build the Card View

The card view defines what users see on the dashboard. Use BasePrimaryTextCardView for most cases:

export class CardView extends BasePrimaryTextCardView<Props, State> {
  public get data(): IPrimaryTextCardViewParameters {
    return {
      title: this.properties.title || 'Leave Balance',
      primaryText: ${this.state.annualLeaveRemaining} days,
      description: Annual leave remaining · Updated ${this.state.lastUpdated},
    };
  }
  public get cardButtons() {
    return [{
      title: 'View Details',
      action: { type: 'QuickView', parameters: { view: QUICK_VIEW_REGISTRY_ID } },
    }];
  }
}

Built-in Card View Templates

Step 4: Build the Quick View

The Quick View is a full Adaptive Card that opens when users click your card:

export class QuickView extends BaseAdaptiveCardView<Props, State, Data> {
  public get data() {
    return {
      annualLeave: this.state.annualLeaveRemaining,
      sickLeave: this.state.sickLeaveRemaining,
      lastUpdated: this.state.lastUpdated,
    };
  }
  public get template(): ISPFxAdaptiveCard {
    return {
      "type": "AdaptiveCard",
      "version": "1.5",
      "body": [
        { "type": "TextBlock", "text": "Your Leave Balance", "size": "Large", "weight": "Bolder" },
        {
          "type": "FactSet",
          "facts": [
            { "title": "Annual Leave", "value": "${annualLeave} days remaining" },
            { "title": "Sick Leave", "value": "${sickLeave} days remaining" },
            { "title": "Last Updated", "value": "${lastUpdated}" }
          ]
        }
      ]
    };
  }
}

You can design Adaptive Cards at adaptivecards.io/designer before embedding them.

Step 5: Test in the Workbench

For SPFx 1.22+, use Heft for development and in-page debugging:

heft build --watch

For legacy projects, use gulp:

gulp serve

This opens the Viva Connections workbench. For testing against real SharePoint data, use the hosted workbench at https://YOUR_TENANT.sharepoint.com/_layouts/15/workbench.aspx.

Step 6: Add a Property Pane

Let administrators configure the ACE without code changes:

export class LeaveBalancePropertyPane {
  public getPropertyPaneConfiguration(): IPropertyPaneConfiguration {
    return {
      pages: [{
        groups: [{
          groupFields: [
            PropertyPaneTextField('title', { label: 'Card Title' }),
            PropertyPaneTextField('listName', { label: 'SharePoint List Name' }),
          ],
        }],
      }],
    };
  }
}

Step 7: Deploy to Viva Connections

Build and package. For SPFx 1.22+, use Heft equivalents:

heft build -p

For legacy projects, use gulp:

gulp bundle --ship
gulp package-solution --ship

Deploy to App Catalog:

• Go to SharePoint Admin Center → Advanced → App catalog

• Upload your .sppkg → click Deploy → check Make this solution available to all sites

Add to Viva Connections Dashboard:

• Open Viva Connections in Teams → click Edit

• Click Add a card → find your ACE → configure → Save and Publish

Advanced: Real-time State Updates

ACEs support periodic background data refreshes:

setInterval(async () => {
  await this._fetchLeaveData();
}, 5  60  1000); // Refresh every 5 minutes

Advanced: Deep-Linking to Teams

public get cardButtons(): [ICardButton] {
  return [{
    title: 'Open in Teams',
    action: {
      type: 'ExternalLink',
      parameters: { isTeamsDeepLink: true, target: 'https://teams.microsoft.com/l/channel/...' },
    },
  }];
}

Common ACE Patterns

Loading State Pattern

Always show a loading state while data fetches:

public async onInit(): Promise<void> {
  this.state = { isLoading: true, data: null };
  try {
    const data = await this._fetchData();
    this.setState({ isLoading: false, data });
  } catch (error) {
    this.setState({ isLoading: false, error: 'Failed to load data' });
  }
}

Multi-View Navigation

// Navigate to next view
this.quickViewNavigator.push(CONFIRM_VIEW_ID);
// Navigate back
this.quickViewNavigator.pop();
// Reset to card view
this.quickViewNavigator.close();

Performance Tips

• Cache API responses. Store fetched data in state and only re-fetch on explicit refresh

• Use Adaptive Card v1.5. It supports more features and renders better on mobile

• Keep card view minimal. Show 2-3 key numbers maximum — the quick view is for details

• Test on mobile. Viva Connections is heavily used on Teams mobile

• Handle 403 errors gracefully. Show a friendly fallback message instead of a broken card

What's Coming for ACEs in SPFx 1.24

• ACE actions without Quick View — Trigger Power Automate flows directly from card buttons

• Image Card View improvements — Animated images and richer layout options

• Enhanced mobile gestures — Swipe actions on cards for quick approvals

• AI-generated card content — Integration point for Copilot-generated summaries in ACE card views

Viva Connections ACEs are the most direct way for SPFx developers to impact the daily experience of every employee in an organization. With mobile-first usage growing and Viva becoming the default Teams home page, the investment in learning ACEs pays dividends quickly.

Related reading: Wire your card actions into business logic with Power Platform custom connectors, or layer in declarative Copilot agents using the Microsoft 365 Agents Toolkit.

FAQ

What is the difference between an ACE and a regular SPFx web part?

A regular SPFx web part renders inside a SharePoint page using the page's full HTML/CSS context. An Adaptive Card Extension renders inside the Viva Connections dashboard using Adaptive Card JSON — a constrained, declarative format optimized for mobile and Teams. Same scaffolding tools, different render pipeline. Use a web part for SharePoint pages, an ACE for the Viva dashboard.

Do I need a Viva Connections license to deploy an ACE?

Viva Connections itself is included in every Microsoft 365 commercial plan that bundles SharePoint Online and Teams, so most enterprise tenants already have it. Your ACE deploys via the SharePoint App Catalog like any SPFx solution — no separate Viva SKU is required to ship the card. End users only need the standard Teams + SharePoint license to see it on the dashboard.

Why is my ACE not appearing on the Viva Connections dashboard?

Three things to check. First, the solution must be deployed tenant-wide in the App Catalog, not just to a single site collection. Second, an admin must add the ACE to the dashboard layout via SharePoint Admin Center → Viva Connections → Edit Dashboard. Third, audience targeting on the dashboard layout can hide the card from your user — confirm you're in any target audience group, or remove targeting while testing.

Can ACE card buttons trigger Power Automate flows directly?

Not yet directly from the card view in SPFx 1.23 and earlier — buttons can only open a URL, navigate to Quick View, or open a Teams deep link. SPFx 1.24 adds "ACE actions without Quick View" which let card buttons invoke a Power Automate flow with no intermediate UI. Until then, the standard pattern is a button that opens Quick View, which calls the flow via a fetch to its HTTPS trigger URL.

How do I test ACE behavior on mobile without deploying every change?

Use the SPFx workbench at https://your-tenant.sharepoint.com/_layouts/15/workbench.aspx?devmode=true in Chrome with the device toolbar set to a mobile viewport (iPhone 14 Pro, Pixel 7, etc.). This catches 80% of mobile rendering issues including touch target sizes and Adaptive Card layout breaks. For the remaining 20% — gesture handling, real network latency, Teams Mobile rendering quirks — deploy to a test site collection and use the Teams mobile app against that site.
